Corsair OPX

Linear Corsair

Corsair OPX switch
Image courtesy of Corsair

Corsair OPX is a short-travel optical linear switch used in select Corsair gaming keyboards, designed for fast actuation in esports-oriented layouts.

Corsair OPX specs

Type Linear
Compatibility Corsair optical boards only
Actuation force 45g
Bottom-out force n/a
Pre-travel 1 mm
Total travel 3.2 mm
Stem n/a
Top housing n/a
Bottom housing n/a
Spring n/a
Factory lube n/a
Pins n/a
Typical price n/a
Sound profile optical gaming linear
Released 2021

Spec fields marked n/a are unpublished by the maker; we list only verifiable numbers rather than guesses.

Unverified: specs compiled from manufacturer listings

Switches similar to the Corsair OPX

Cherry MX Speed Silver Linear The Cherry MX Speed Silver is Cherry's fast-actuation 45g linear, cutting pre-travel to 1.2mm and total travel to 3.4mm for quicker inputs in games. Compare: Corsair OPX vs Cherry MX Speed Silver · popular
Kailh Speed Silver Linear The Kailh Speed Silver is a 40g linear that actuates at just 1.1mm, one of the earliest and most popular "speed switch" designs for gaming keyboards.
Gateron G Pro Red Linear The Gateron G Pro Red is a light pre-lubed 45g linear that ships stock in many Keychron boards and works as a cheap, dependable gaming switch. Compare: Corsair OPX vs Gateron G Pro Red

Keyboards sold with the Corsair OPX

Corsair K65 Pro Mini 65% · $130 The Corsair K65 Pro Mini is a 67-key wired 65% gaming keyboard with Corsair OPX linear optical switches, PBT double-shot keycaps, and up to 8,000Hz polling via AXON, though its switches are soldered rather than hot-swappable.

Which keyboards can use it?

The Corsair OPX needs a keyboard built around Corsair's own optical-sensing PCB; optical light gates are proprietary, so switches from other optical makers do not fit, such as the Corsair K65 Pro Mini. It is not compatible with standard MX mechanical hot-swap sockets. Check the keyboard manufacturer's supported-switch list before buying.
